TracStar 卫星功放 -40W. Ku-Band BUC



40W Ext. Ku-Band BUC This unit features: Smallest and lightest size and weight Output frequency range 13.75-14.5GHz Double - L.O. (electronically switchable 12.80/13.05GHz



This unit features:

Smallest and lightest size and weight

Output frequency range 13.75-14.5GHz

Double - L.O. (electronically switchable 12.80/13.05GHz)

Auto-ranging AC (80-240VAC) or DC (36-58 VDC) power option

Low power consumption (<262 W)

Digital temperature compensation

L.O. lock and amplifier LED

M&C - combined RS-232/485 and Optional FSK

Model

RF Frequency

Local Frequency

IF Frequency

Output Power

Connector

40  X

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

40W (+46 dBm min.)

N-type

40 XF

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

40W (+46 dBm min.)

F-type



 - 40W Ext. Ku-Band BUC







Parameter

Value

Output interface

Waveguide, WR-75

Output power @ P1 dB

+46 dBm minimum over temperature

Conversion gain

68 dB nom.

Required frequency

External referenceinput power

Phase noise

10 MHz (sine-wave)
-5 to +5 dBm @ input port
-55 dBc/Hz max. @ 10 Hz
-65 dBc/Hz max. @ 100 Hz

-75 dBc/Hz max. @ 1 KHz



-85 dBc/Hz max. @ 10 KHz

-95 dBc/Hz max. @ 100 KHz

-120 dBc/Hz max. @ 1 MHz



Input V.S.W.R.

2:1 max

Output V.S.W.R.

2:1 max





Parameter

Value

Power requirement

Option: AC (80-240VAC) or DC (36-58VDC) power supply



Mute

Shut off the HPA in case of L.O. unlocked

Input interface

N-type, female (50 Ohm) ABD40KX

F-type, female (75 Ohm)

ABD40KXF

Power consumption

262 W max.

Operating temperature

-40 to +55 degrees C

Storage temperature

-40 to +75 degrees C

Size & Weight

270 mm (L) x 120 mm (W) x 120.6 mm (H), 10.62”(L) x 4.72” (W) x 4.74” (H), 3.67 kg max. (8.1 lbs max.)
